Colloid Mill Machine

Colloid mill machine is a wet material fine processing machine, widely employed in the food, pharmaceutical, and chemical industries for various applications such as the production of peanut butter, chili sauce, cocoa paste, jam, and more. At Tianzhong Machinery, our colloidal machine is made of stainless steel, providing excellent corrosion resistance and wear resistance. This design ensures that the processed materials remain pollution-free and hygienic.

Colloidal Mill Specifications

JMS-50 Colloid Mill for Sale
Small Colloid Mill for Sale
Colloid Mill Machine
Colloid Mill Machine
Model JMS-80 JMS-110 JMS-130 JMS-160 JMS-180 JMS-210 JMS-240 JMS-300
Fineness 50-200 mesh
Capacity(kg/h) 60-80 100-200 300-500 500-600 700-800 1,000-1,200 1,200-1,500 3,000-4,000
Power(kW) 4 7.5 11 15 18.5 30 45 75
Voltage(V) 380 380 380 380 380 380 380 380
Weight(kg) 150 175 285 300 375 700 920 1,300
Dimension(mm) 600*410*930 700*430*1,000 990*440*1,000 1,000*460*1,050 1,000*490*1,100 1,260*600*1,230 1,330*630*1,280 1,440*680*1,420
Hopper Capacity 8L 8L 14L 14L 14L 24L 24L 32L
Rotor Diameter 80mm 110mm 130mm 160mm 180mm 210mm 240mm 300mm
Rotary Speed 2,890 r/min 2,900 r/min 2,930 r/min 2,930 r/min 2,930 r/min 2,950 r/min 2,970 r/min 2,970 r/min

Below are the customizable options of Tianzhong’s colloid mill.

1. Vertical or horizontal design; fixed or movable configurations.
2. Various feed options: pump, hopper, or screw feeder.
3. Multiple choices for stator and rotor with different fineness options, different tooth designs and materials.
4. Adjustable grinding gap.
5. Different machine construction materials: 2Cr13, 304, 316, or duplex stainless steel.
6. Different options of discharge method, namely, circulating pipe (suitable for materials that require circular grinding) or square discharge outlet.

What is A Colloid Mill?

A colloid mill is a mechanical apparatus that utilizes the relative movement of rotors and stators to process wet materials. Functioning as a kind of grinding equipment, the colloid mill operates on the principle of shearing and grinding materials between a series of rotors and rotating stators at high speed. When the material passes through the gap between the stator and rotor, it undergoes intense mechanical forces that break down the particles or droplets to the desired size. The processed particles typically range from 50 to 200 meshes, with a homogeneity exceeding 90%, making it an ideal device for fine material processing.

This machine consists of grinding units, base transmission part and electric motor. The core of the colloid mill consists of the shell, stator, and rotor. The main body of the colloid mill is crafted from high-strength stainless steel. And the stator and rotor especially undergo a strengthening process, offering excellent corrosion resistance and wear resistance. In essence, a colloid mill is not just a grinding machine; it’s a precision tool that excels in creating finely dispersed and homogeneous mixtures. Its unique ability to handle materials with higher viscosity and larger particles.

Peanut Butter Grinder
Peanut Butter Mill
Colloid Mill Machines for Sale
Colloid Mill Machines for Sale

What Does a Colloid Grinder Do?

The primary functions of a colloid mill machine include:
1. Dispersion: Breaking down materials into fine particles and achieving uniform distribution.
2. Comminution: Crushing and reducing particle size to the desired range.
3. Emulsification: Creating stable emulsions by blending immiscible liquids.
4. Homogenization: Achieving a consistent and uniform mixture of components.
5. Mixing: Thoroughly blending different substances to create a homogeneous product.

Uses of Colloid Mill

Colloidal mill is suitable for manufacturing of various materials. Below are its common applications:

1. Food Industry:
Colloid mills are employed in the production of dairy products, chocolate manufacturing, the production of fruit jams, production of peanut butter, cream, various sauces, etc.

2. Chemical Industry:
It is also employed in the chemical industry for the production of pigments or paints, manufacturing of lubricating oil, flavorings, emulsified rubber, catalysts, and more.

3. Pharmaceutical Industry:
Used in the processing of fish liver oil, balsams, royal jelly, and pollen for other pharmaceutical products.

4. Cosmetic Industry
More than that, colloid mills are also widely used in the cosmetic industry, such as shampoos, hair care products, toothpaste, soaps, detergents, and more.

Uses of Colloid Mill
Uses of Colloid Mill

Features of Colloid Mill Machine

1.The main components of the colloid mill are made of high-quality stainless steel, ensuring corrosion resistance and non-toxicity.
2. The stator and rotor adopt special machining and heat treatment processes, with high processing precision and long service life.
3. The stator and rotor can be made from different materials and with various grinding and shearing structures and tooth types, providing a wide range of options to meet your specific needs.
4. The processing gap between stator and rotor can be finely adjusted through a control ring, making it easy to control and ensuring the processing quality of the product. In addition, the main body and control ring are equipped with positioning and locking devices, ensuring the stability of the processing gap.
5. There is a cooling system to ensure the properties of the processed materials.
6. We also offer options between a regular motor and an explosion-proof motor. You can choose according to your specific needs.

Colloid Mill Working Principle

The colloid mill operates by the relative motion of rotors and stators under the power of electric motor. The rotor rotates at a high speed, while the stator remains stationary. The processed material is processed through shear forces, frictional forces, high-frequency vibrations. This powerful combination of forces efficiently emulsifies, disperses, homogenizes, and pulverizes the material, achieving a finely ground and emulsified product. By the way, the gap between the rotor and stator is adjustable according to various materials to control the size of the particles or droplets produced. A smaller gap results in finer particles or droplets.

1. Rotor and Stator

Rotor is a rotating disc, and the stator is a stationary component. The rotor is equipped with blades, teeth, or cutting surfaces. The high-speed rotation of the rotor generates centrifugal forces. When the material passes through the gap between the stator and rotor, it is effectively broken, dispersed, and emulsified. Tianzhong Machinery also offers various options of grinding teeth, made of different materials, including martensitic stainless steel (vacuum quenching or QPQ process), alloy spraying, and diamond spraying.

2. Adjustable Gap

The adjustable gap between the rotor and stator allows to control the size of the particles produced by the mill. Change the gap by turning the adjusting handle, and the adjusting ring drives the axial displacement of the stator.

3. Drive System

The drive system provides the necessary power to rotate the rotor at high speeds. It typically includes an electric motor that drives the rotor.

Colloid Mill Structure
Colloid Grinder Structure

Types of Colloid Mill Machines

1. Vertical Colloid Mill

The vertical colloid mill is driven by an electric motor, which, through belt transmission, rotates the rotor at high speed. The vertical structure occupies a small area, allowing for long operating times, reduces eccentricity of the shaft, and facilitates easy replacement. Moreover, it can be operated by personnel with basic training.

2. Horizontal Colloid Mill

The horizontal colloid mill is powered by an electric motor, driving the rotor at high speed. But the horizontal structure is prone to eccentricity issues, requires professional personnel to replace the internal structure and damaged grinding heads and shafts.

Structurally, the vertical type uses belt transmission, allowing for a speed increase of 3-5 times compared to the motor alone, resulting in better grinding efficiency compared to the horizontal colloid mill. However, the motor and the grinding part of the horizontal colloid mill are separated. The motor is safer if the material moisture splashes out.

Designs of Rotor and Stator
Designs of Rotor and Stator
Peanut Butter Production Line
Peanut Butter Production Line

How to Choose Colloid Grinder?

Choosing the right colloid mill machine involves considering several factors to ensure optimal performance and efficiency. Here are key factors to consider:

1. Material Flowability
– High Flowability: If the material has good flowability, you can opt for a smaller model.
– Poor Flowability: For materials with poor flowability, a larger model with increased power is necessary to prevent strain on the motor and ensure a longer lifespan.

2. Particle Size of Material
If the material has large particles, it is advisable to choose a colloid mill with a larger inlet size. Or please pre-process the material to reduce particle size before feeding it into the colloid mill. Tianzhong Machinery also offers crushers to choose from.

3. Capacity Requirements
Consider the required production volume and choose a colloid grinder with a corresponding capacity. Selecting a machine with the right output ensures efficiency and prevents overloading. Besides, if the material is difficult to grind, choose a machine with wear-resistant stator and rator to enhance durability and reduce maintenance needs. Welcome to contact our professional team to get more details!

FAQs About Colloidal Mill

1. Q: Is it necessary to roast or soak nuts before grinding? And why?

A: Yes. If you want nut butter or paste, you need to roast the nuts first; if you want nut milk, you need to soak the nuts first. It is because that our colloid mill is a wet grinding equipment, which is used to grind fluid raw materials. When roasting nuts, the oil of nuts can be fully released, and then get perfect nut butter. While it can increase the moisture of nuts, then it helps to get the best nut milk if soaking nuts first.

2. Q: Is colloid mill the same as the homogenizer?

A: The short answer is no. In essence, colloidal mills and homogenizers serve similar purposes in terms of particle size reduction and emulsion formation. But they are distinct pieces of equipment with some differences.

Conclusion

In conclusion, the colloid mill machine from Tianzhong Machinery stands out as a precision tool in achieving finely dispersed and homogeneous mixtures. Its robust features, customizable options, and versatility make it an indispensable asset across various industries. Choose Tianzhong Machinery for superior colloid mill solutions, ensuring efficiency, reliability, and product quality. Contact us today to discuss more details to meet your specific requirements.
