Trash Can Dumper

Trash can dumper, developed by Tianzhong Machinery, is an innovative auxiliary device designed to greatly enhance the automation level in the solid-liquid separation process. This efficient machine is used for easy and quick emptying or dumping of heavy trash cans.

Tianzhong Machinery provides a diverse range of bin lifters, catering to trash cans ranging in capacity from 120 L to 1,000 L, with weights of up to 1,000 kg. With their reliable performance and user-friendly operation, these bin lifters are widely used in the waste disposal and food processing industry. We are pleased to provide this machine as a standalone solution or as auxiliary equipment for dewatering system. For further details, please feel free to get in touch with us.

Trash Can Dumper
Trash Can Dumper
Garbage Can Lifter
Garbage Can Lifter
New Design of Garbage Can Lifter
New Design of Trash Can Lifter

Specifications of Trash Can Dumper

Items Specifications
Bin Capacity 120L, 240L, 360L, 660L, 1,000L
Lifting Height 1.6m- 3m (can be customized as requests)
Weight Capacity 50kg-1,000kg
Dumping Angle 135°
Lifting Speed 1-2 times/minute
Power Source Electric or Hydraulic

Features

The trash can dumper offers a range of features that make it a versatile and efficient solution.

1. Chain-driven Mechanism
Utilizing a chain-driven lift mechanism, the trash can dumper enables a lifting height ranging from 1.6 meters to 5 meters. This simple yet effective design offers benefits such as low maintenance requirements and energy efficiency.
2. Customizable Design
The garbage can lifter can be customized to handle load weight ranging from 50 kg to 1,000 kg, and can accommodate various bin sizes and shapes, including the standard options such as 120L, 240L, 360L, 660L, and 1,000L models. Moreover, Tianzhong Machinery provides both hydraulic and electric lifters, offering flexibility to meet your specific requirements. You can also choose different colors and materials.
3. Optimal Dumping Angle
The dumper is capable of smoothly tilting garbage bins at an angle of 135 degrees, allowing efficient and controlled dumping of waste.
4. Adjustable Lifting Speed
The garbage can dumper offers a lifting speed of 1 to 2 times per minute. This feature enables efficient waste disposal and a safe operation.
5. Versatility
The trash can lifter is capable of handling various types of containers, including metal drums, plastic bins, square or round buckets, and more. It can be used with different types of vehicles, such as tractors, and is suitable for various stations, mobile setups, or fixed platforms, providing versatility in waste disposal scenarios.
6. Compact Design and Small Footprint
This design allows it to occupy minimal space, making it ideal for environments where space is limited. Besides, it can be easily integrated into existing waste management systems.
Different Designs of Trash Can Lifter
Design of Trash Can Lifter

What Is a Trash Can Dumper?

A trash can lifting machine consists of several essential components, including a motor, hydraulic system, bracket, dual chains, hook, and electric control system. The frame is designed to hold and secure the trash can during the dumping process. The lifting mechanism uses chain and hydraulic system or motor, which grabs and raises the trash can. Once the can is inverted, gravity helps to empty the contents into the awaiting container or hopper.

Usage Instructions

Using the trash can dumper is straightforward and user-friendly. Follow these instructions for seamless operation:

1. Place the garbage bin onto the lifting platform, ensuring that the bin’s front edge aligns with the teeth of the lifting mechanism.
2. Activate the “Up” button to initiate the automatic lifting process. The trash can lifter will raise the garbage bin.
3. The device will automatically tilt the garbage bin, allowing the waste to be emptied. Once the dumping process is complete, press the “Down” button.
4. The dumper will lower the garbage bin back to the ground, ensuring a stable landing before removing the emptied bin.
Additionally, there is a red emergency brake button on the control panel. In case of any emergency, pressing this button will immediately halt the operation.

Below is a video for your reference. You can also follow us for more videos.

Key Reasons for Using a Trash Can Lifter

1. Automation and Labor Efficiency: Trash can lifter automate the process of lifting, tilting, and emptying garbage bins, reducing the need for manual handling. This automation streamlines waste disposal and dewatering procedures, saving time and labor costs.

2. Improved Safety: Manual handling of heavy trash cans can lead to workplace injuries, strains, and accidents. By using a trash can dumper, the risk of employee injuries is significantly reduced, promoting a safer working environment.

Conclusion

Tianzhong Machinery’s trash can dumper serves as a valuable auxiliary device with screw press separation system. This innovative equipment features automating the lifting, tilting, and disposal of various garbage bin sizes and weights. With its user-friendly design, customizable features, the dumper greatly enhances work efficiency while saving labor costs in waste management and food processing industry. If you have any questions, please contact us!
