Food Waste Treatment System

Tianzhong Machinery offers a series of all-in-one food waste treatment system, which is effective in volume reduction through the process of “solid liquid separation, oil-water separation, fermentation”. This equipment is ideal for kitchen waste treatment plants, restaurants, hotels, schools, food processing plants, and other food service establishments. With daily processing capacities ranging from 1 ton to 10 tons, our machines provide efficient solutions for managing food waste. Welcome to contact us for more details!

All-in-one Food Waste Treatment System
All-in-one Food Waste Treatment System
Food Waste Treatment System
Kitchen Waste Treatment System

Integrated Kitchen Waste Treatment Equipment for Sale

Model TZ-YTJ-1 TZ-YTJ-3 TZ-YTJ-5 TZ-YTJ-10
Daily Processing Capacity 1 ton 3 tons 5 tons 10 tons
Installed Power (kW) 30 41.8 56.8 71.8
Floor Area (m²) 12 15 20 30
Total Weight (kg) 3,800 5,000 6,800 9,800
Voltage (V) 380
Operating Temperature (℃) -10-50
Main Material SS304 Stainless Steel
Heating Method Electric Heating
Temperature Control Range (℃) 55-65
Operating Noise (dB) ≦75
Control System Automatic/Manual + Remote Control
Shipping Kitchen Waste Treatment Equipment
Shipping to Client
Installation Site
Installation Site

ROI of Kitchen Waste Treatment Equipment

Integrated kitchen waste treatment equipment offers a comprehensive solution for processing kitchen waste. Let’s overview what we can get from such equipment.

Cost Savings

Through our equipment, the volume of waste is reduced by approximately 80%, resulting in lower transportation and landfill costs. For example, about 150 kg of residue remains when processing 1 ton of kitchen waste through oil-water separation, degradation, and dewatering.

Turning Waste into Wealth

The remaining 20% of solid residue and the separated waste cooking oil can undergo further process to produce organic fertilizer and biodiesel, which can bring your additional economic benefits.

Environmental Benefits

Investing in a food waste dewatering machine aligns with sustainability goals and environmental regulations. The equipment is able to recycle organic waste into valuable resources and reduce environmental pollution.

If you want to evaluate the ROI of integrated kitchen waste treatment equipment, you need to analyze the purchasing costs of equipment, operating costs, as well as the benefits and savings it can provide. Welcome to talk with our team for a suitable solution to your specific needs.

Features of Food Waste Treatment System

1. Low Operating Cost

The screw press machine uses physical extrusion and without the need for additional heat sources, resulting in low energy consumption and low operating costs.

2. High Processing Capacity with Continuous Operation

The system is designed for efficient handling of food waste, ensuring large-scale processing capabilities and uninterrupted operation.

3. Low Moisture Content in Dewatered Solids

The dewatering process effectively removes moisture from the solids, resulting in about 50-60% moisture content in the final residue.

4. Excellent Wear and Corrosion Resistance

The key components of thescrew press dewatering machineare coated with a wear-resistant layer. While the critical parts, including screw and screen, are made of 304 stainless steel, which prolongs the equipment’s service life.

5. Customizable Design

The screen opening sizes ranges from between 0.3mm and 1.0mm, which can be customized according to the properties of the materials being processed. Besides, we also offer custom solution, including the feeding equipment, control system, and more to meet specific requirements.

Parts of Food Waste Treatment System
Parts of Food Waste Treatment System
Food Waste Treatment System
Food Waste Treatment System

Working Process of Kitchen Waste Treatment System

Feeding: The kitchen waste or fruit and vegetable waste is collected and transported to the treatment facility. Before entering the machine, any inorganic materials such as glass bottles, metals are removed.
Shredding: The organic waste is fed into a shredder, where it is cut into smaller pieces to facilitate further processing.
Solid-Liquid Separation: The shredded food waste then goes into screw press machine for dehydration. During this process, the solid and liquid components are separated, and the liquid fraction undergoes oil-water separation equipment.
Oil-Water Separation: The liquid mixture obtained from the previous step gradually enters the oil-water separation zone. Here, the oil and water gradually separate, achieving a removal rate of over 90% for the oil content.
Fermentation: The dewatered solid material is conveyed to a high-temperature fermentation chamber. Within this chamber, organic compounds are effectively decomposed. The final product of the fermentation process can be used as organic fertilizer.
Integrated Kitchen Waste Treatment Equipment
Integrated Kitchen Waste Treatment Equipment


Tianzhong Machinery is your trusted partner in food waste treatment solutions. By investing in our integrated kitchen waste treatment equipment, you can enjoy numerous benefits. Not only will you reduce your waste disposal expenses, but you will get additional economic and environmental benefits. At Tianzhong Machinery, we will provide reliable equipment, as well as full service. Contact our team to discuss your specific needs and explore a suitable solution for your projects.
